0.9mm LC Fiber Optic Connector Multimode And Singlemode Simplex For CATV and WAN

Name: 09mm LC Fiber Optic Connector Multimode And Singlemode Simplex For CATV and WAN
Brand: FOCABLE
Price: 1 USD

Buy cheap 0.9mm LC Fiber Optic Connector Multimode And Singlemode Simplex For CATV and WAN product

Brand Name : FOCABLE

Model Number : LC/UPC Multimode Fiber Optic Connector

Certification : ISO Certificate, RoHS Compliant

Place of Origin : China

MOQ : 100PCS

Supply Ability : 900000PCS/Month

Packaging Details : 100PCS/Bag

Connector Outer Diameter : 3.0mm, 2.0mm, 0.9mm

Connector : FC, SC, ST, LC, SMA, E2000, MPO, MTRJ

Polishing Type : UPC, APC

Cores : Simplex, Duplex

Fiber : SM, MM-OM1, MM-OM2, MM-OM3, MM-OM4

Material : Plastic Housing, Metal Housing

Contact Now

0.9mm LC Fiber Optic Connector Multimode And Singlemode Simplex For CATV and WAN

The LC family of single mode and multimode connectors, adapters and associated components are known as lucent technologies. The LC is a small form factor(SFF)connector and is ideal for high density applications. The LC connector has a zirconia ceramic ferrule measuring 1.25mm with either a PC or APC end face, and provides optimum insertion and return loss. The LC connector is used on small diameter mini-cordage(1.6mm/2.0mm)as well as 3.0mm cable.

Features
RJ-45 style housing with push-pull coupling mechanism which allows easy disengagement in dense spaces.
Small Form Factor-Half the size of duplex SC and ST connectors
Simplex and duplex assemblies available in standard and custom configurations
Single mode and Multimode
PC finish
Compliant with Telcordia GR-1435-CORE specification

Specifications

Type	Single Mode (angled)	Single Mode (PC)	Multimode (PC)
Insertion Loss	≤0.30dB	≤0.3dB	≤0.3dB
Return Loss	≥65dB	≥55dB	≥25dB
Operating Temperature	-40℃ to +80℃	-40℃ to +80℃	-40℃ to +80℃

Applications
Telecommunication
CATV Systems
LAN and WAN
Network
Broadband
FTTX
Test Equipments

Our Advantages
Experienced Staff
Green Product
Guarantee/Warranty
Perfect Product Performance
Prompt Delivery
Small Orders Accepted
